DRAWWORK
Emsco D2
Grooved for 11⁄4″ Drill Line
Clutchco Eaton 236 WCBD Water Cooled Brake
DERRICK
Baker
136′ High, Triple Cantilever
600,000# Static Hook Load Capacity with 10 lines
SUBSTRUCTURE
Superior
16’ Rotary Beam Clearance, 21’7” RKB
22′ Rotary Beam Clearance, 27’7” RKB with 6’ Pony Sub
POWER SOURCE
2-Caterpillar C-15 Diesel Engines 950 HP
2-National Model C 195-80 Type F Torque Converters Two Engine Split Oil Bath Compound
(1) Gardner Denver ADL Air Compressors
PUMPS
(2) Emsco type F-1600 7″ x 12″ Triplex Powered by Cat 3512 with 28” Double WPT Clutch Low Pressure Mud Mixing System with Two 5″ x 6″ Centrifugal Pumps w/60 HP Electric Motors
DRILL STRING
Drill Pipe – 41⁄2″ Grade G-105 16.60, X-Hole with Hardband Drill Collars – 6” – 61⁄2” OD NC44 with Hardband
7” – 71⁄4” OD 5” H90 with Hardband Kelly – Drilco 51⁄4″ x 40′ Hex
Pipe Spinner Kelly Spinner
PREVENTERS
1- GK Hydrill 11” 1500 Series Annular wp 5000#
1- NL Shaffer 11” Type LWS 5000# Space Saver Double Rams
1-Koomey Type 80 7 Station 3000 psi with (12) 10 Gallon Bladder Type Bottles with Electric Triplex Pump and 2 Air Pumps, (1) remote station
Choke Manifold-5000 psi 4″ x 2″ with Two Adjustable Chokes
OTHER EQUIPMENT
250 Ton Hydraulic Warrior Top Drive
Crown Block – (7) 56″ Sheaves, 350 Ton
Traveling Block – 350 Ton Capacity
Swivel – Ideco 400
Weight Indicator – Martin Decker Type E
Rotary – 271⁄2″ x 531⁄4″ 275
Generators – Two 410 KW with 2-C15 CAT Tier 4 @ 626 H.P. each Air Compressors – (2) Sullivan 300-DG-TE Screw Type
Fuel Tank with Lubester – 10,000 Gallon
Wireline Unit – Mathey Model GC-B2 type, .092 Line
Mud Tanks – Two Tank System 670 Barrels with Electric Agitators
Shakers – (2) Derrick 503 Linear Motion
Desander – Derrick, (2) 12″ Cones with Mission Magnum 5″ x 6″ Centrifugal Pump w/75 HP Electric Motor Desilter – Derrick, (12) 4″ Cones with Mission Magnum 5″ x 6″ Centrifugal Pump w/75 HP Electric Motor Degasser – Derrick Drilco type
Pason Automatic Driller
500 Barrel Drill Water Tank
